| 브랜드 이름: | UVIR |
| 모델 번호: | THG100009 |
| 모크: | 협상 가능 |
| 가격: | 협상 가능 |
| 지불 조건: | L/C,T/T,웨스턴 유니온,머니그램 |
| Attribute | Value |
|---|---|
| Material | Quartz tube |
| Coating | Gold |
| Warranty Time | 5000 Hours |
| Filament | Tungsten Wire |
| Power | 55-575V |
| Voltage | 200-6000W |
| Total length | 50-1500mm |
| Heating length | 50-1500mm |
| Line length | 50-1500mm |
| Type | B |
| Twin Tube Cross-Section | Maximum Length (m) | Short Wave | Medium Wave |
|---|---|---|---|
| 8×18 | 2.1 | N | Y |
| 23×11 | 3.5 | Y | Y |
| 33×14 | 4.0 | Y | Y |
| Voltage (V) | Wattage (W) | Twin Tube | Total Length | Heated Length | Design Type | Gold | White | Clear |
|---|---|---|---|---|---|---|---|---|
| 55 | 400 | 11×23 | 115 | 50 | B | THG100151 | THW100025 | THC100026 |
| 115 | 400 | 11×23 | 115 | 50 | B | THG100152 | THW100026 | THC100027 |
| 115 | 450 | 11×23 | 70 | 25 | B | THG100153 | THW100027 | THC100028 |
| 115 | 600 | 11×23 | 145 | 80 | B | THG100155 | THW100029 | THC100030 |
| 115 | 1100 | 11×23 | 205 | 140 | B | THG100158 | THW100032 | THC100033 |
| 230 | 3000 | 15×33 | 650 | 500 | C | THG100165 | THW100039 | THC100040 |
| 400 | 4800 | 15×33 | 500 | 800 | B | THG100141 | THW100062 | THC100062 |
| 480 | 6000 | 15×33 | 1550 | 1000 | B | THG100140 | THW100065 | THC100065 |
